A geared electric trolley mounted electric wire rope hoist that travels along I-beam runways — built for overhead cranes and single-girder & double-girder systems that need horizontal travel, not just fixed-point lifting.
The CD1 & MD1 electric wire rope hoist with electric trolley pairs a compact, lightweight hoist body with a geared electric trolley, giving the unit powered horizontal travel along I-beam runways in addition to smooth vertical lifting. Available in rated capacities from 0.5t to 20t with standard lifting heights of 6m to 30m, it is designed for overhead rail installations and works with a full range of crane types — single-girder cranes, double-girder cranes, jib cranes and gantry cranes — where loads need to move along a fixed path, not just up and down.
It is offered in two operating configurations: the CD1 single-speed model delivers dependable performance for standard lifting duties, while the MD1 dual-speed model adds fine speed adjustment for precision assembly and accurate load positioning. Built with robust core components including a gear reducer, drum assembly, lifting motor, tapered brake system and heavy-duty hook, it delivers long-lasting reliability for daily industrial operation.
Compact, lightweight and small-sized structure with steady running performance, well adapted to limited installation space and daily lifting operations.
Available in CD1 single-speed and MD1 dual-speed versions. MD1 dual-speed model enables precise speed adjustment for fine positioning and precision assembly work.
Suitable for overhead rail mounting, and compatible with single-girder, double-girder, cantilever and gantry cranes to meet diverse material handling demands.
Built with high-quality core components including gear reducer, drum unit, tapered brake, lifting motor and hook device for long-lasting reliable industrial performance.
Not every lifting job is limited to fixed-point vertical lifting. Where loads need to travel horizontally along overhead runways across workshops, warehouses or production yards — a trolley-mounted wire rope hoist delivers efficient long-distance material handling with stable heavy-load capacity. The CD1 & MD1 series is built for exactly that: dependable, heavy-duty lifting and travel for daily industrial operations.
Which CD1 model fits your job?
The CD1 single-speed electric wire rope hoist delivers steady, reliable performance for standard material handling and regular lifting duties. It is compatible with single-girder, double-girder, cantilever and gantry cranes, with rated capacities from 0.5t to 20t and standard lifting heights from 6m to 30m, to match a wide range of industrial load and travel requirements.
Compare: CD1 Electric Wire Rope HoistCompare: DLER Electric Wire Rope Hoist
| Model | CD1-0.5T | CD1-1T | CD1-2T | CD1-3T | |||||||||||||||||||
| Lifting capacity | (t) | 0.5 | 1 | 2 | 3 | ||||||||||||||||||
| Lifting height | (m) | 6 | 9 | 12 | 6 | 9 | 12 | 18 | 24 | 30 | 6 | 9 | 12 | 18 | 24 | 30 | 6 | 9 | 12 | 18 | 24 | 30 | |
| Lifting speed | (m/min) | 8 | 8 | 8 | 8 | ||||||||||||||||||
| Running speed | (m/min) | 20(30) | 20(30) | 20(30) | 20(30) | ||||||||||||||||||
| Rope diameter | (mm) | 5 | 7.7 | 11 | 13 | ||||||||||||||||||
| Type of I-Beam（GB706-88) | 16-28b | 16-28b | 20a-32c | 20a-32c | |||||||||||||||||||
| Lifting motor | (Kw) | 0.8 | 1.5 | 3 | 4.5 | ||||||||||||||||||
| Running motor | (Kw) | 0.2 | 0.2 | 0.4 | 0.4 | ||||||||||||||||||
| Voltage | (V) | 380(220-660) | |||||||||||||||||||||
| Frequency | (Hz) | 50/60Hz | |||||||||||||||||||||
| Phase | (ph) | 3 | |||||||||||||||||||||
| Protection Level | IP44 IP54 | ||||||||||||||||||||||
| Working Level | M3 | ||||||||||||||||||||||
| Institution level | 25% | 25% | 25% | 25% | |||||||||||||||||||
| Minimum Turning Radius | (m) | 1 | 1 | 1.8 | 1 | 1 | 1.2 | 1.8 | 2.5 | 3.2 | 1.2 | 1.2 | 1.5 | 2 | 2.8 | 3.5 | 1.2 | 1.2 | 1.5 | 2 | 2.8 | 3.5 | |
| Net Weight | kg | 121 | 125 | 130 | 137 | 145 | 172 | 188 | 204 | 220 | 221 | 232 | 285 | 309 | 332 | 353 | 281 | 297 | 354 | 390 | 420 | 451 | |
| Model | CD1-5T | CD1-10t | |||||||||||
| Lifting capacity | (t) | 5 | 10 | ||||||||||
| Lifting height | (m) | 6 | 9 | 12 | 18 | 24 | 30 | 9 | 12 | 18 | 24 | 30 | |
| Lifting speed | (m/min) | 8 | 7 | ||||||||||
| Running speed | (m/min) | 20(30) | 20(30) | ||||||||||
| Rope diameter | (mm) | 15.5 | 15.5 | ||||||||||
| Type of I-Beam（GB706-88) | 25a-45c | 32b-63c | |||||||||||
| Lifting motor | (Kw) | 7.5 | 13 | ||||||||||
| Running motor | (Kw) | 0.8 | 0.8×2 | ||||||||||
| Voltage | (V) | 380(220-660) | |||||||||||
| Frequency | (Hz) | 50/60Hz | |||||||||||
| Phase | (ph) | 3 | |||||||||||
| Protection Level | IP44 IP54 | ||||||||||||
| Working Level | M3 | ||||||||||||
| Institution level | 25% | 25% | |||||||||||
| Minimum Turning Radius | (m) | 1.5 | 1.5 | 1.5 | 2.5 | 3 | 4 | 1.5 | 1.5 | 2.5 | 3 | 4 | |
| Net Weight | kg | 473 | 495 | 597 | 646 | 686 | 726 | 1048 | 1098 | 1209 | 1310 | 1411 | |
If the load only needs vertical lifting at a fixed position, a stationary wire rope hoist is the simpler choice. If you require horizontal travel along overhead runways, the CD1 trolley-mounted model delivers powered movement along I-beam tracks.
Choose from 0.5t to 20t rated capacity based on your heaviest working load, plus a proper safety margin for reliable daily operation.
Confirm the trolley’s compatible I-beam type and flange width range match your on-site overhead runway beam before ordering.
Select from standard 380V (220–660V optional) power supply and 6m to 30m lifting height to match your site’s electrical standards and working requirements.
Small-sized, light structure with minimal footprint, easy to install and well adapted to limited overhead workspace.
Single-speed lifting and travel deliver stable, jolt-free performance, ideal for daily routine material handling.
Fits overhead rails and works with single-girder, double-girder, cantilever and gantry cranes.
Rated capacity ranges from 0.5t to 20t, with standard lifting heights of 6m to 30m for diverse demands.
Built with high-grade gear reducer, drum unit, tapered brake and lifting motor for long service life.
IP44/IP54 protection class and M3 working level ensure durable performance in harsh workshop environments.
From what positions can the CD1 hoist lift?
It is used for lifting and transporting goods in workshops, warehouses and factories, capable of vertical lifting plus horizontal travel along I-beam track.
How does the safety mechanism work?
The hoist is equipped with a built-in brake system and overload protection device to prevent slipping and overloading during lifting and lowering. It also features upper and lower limit switches to avoid overwinding.
What lifting heights are available?
Lifting height ranges from 6m on the standard model up to 30m on customized models, covering general and high-lift working conditions.
What is it made of?
It is manufactured with high-strength cast iron gearbox, durable steel wire rope, high-performance lifting motor and heavy-duty trolley assembly.
Tell us your capacity, lifting height, and working‑condition requirements — we'll confirm the correct model and send pricing.
