The DLEDP electric chain hoist with electric trolley pairs a lightweight yet rugged aluminum alloy hoist body with a geared electric trolley, giving the unit powered horizontal travel along I-beam runways in addition to vertical lifting. Available in capacities from 500 kg to 5 tonnes with a 3 m standard lifting height, it is offered in both single-speed and dual-speed configurations, and built for monorail cranes, single-girder crane runways and workshop assembly lines where loads need to move along a fixed path, not just up and down.

It features a fully-sealed heat-dissipating aluminum shell adapted to harsh working environments, and comes standard with inverse phase protection, upper and lower limit switches, 24V&36V safety control voltage and side magnetic instant braking, paired with Japan FEC80 ultra heat-treated steel alloy chain for reliable safety and long service life.

Why Choose a Trolley-Mounted Electric Chain Hoist?

Not every lifting job needs low headroom design or fixed-point suspension. When loads need to be lifted, lowered and moved horizontally along I-beams — workshop production lines, warehouse cargo handling, equipment maintenance area — a trolley-mounted electric chain hoist delivers flexible travelling performance. Compared with hook suspended type, it realizes integrated lifting & traversing, improves handling efficiency and saves overall installation cost. The DLEDP is built for exactly that: reliable lifting plus powered horizontal movement.

Which DLEDP model fits your job? If your ceiling clearance is limited, the DLEDP low headroom electric trolley hoist maximizes available lifting height with compact structure. If you only need lifting work at one fixed position, the DLF hook type hoist is simpler and more cost-effective. If you need to move goods along the beam runway, the DLEDP electric trolley hoist provides powered horizontal travel together with lifting function.Compare: DLEDP with Electric Trollry Compare: DLTDP with Manual Trolley
