Technical parametersModelCapacity （t）Test load （t）Protection levelClassification FEM/SOLifting speed ( m/min)Motor (kw)Load chain （mm)Load chain fallsNet weight (kg)Chain/M (kg)DSNN-S3-0.50.50.625IP 661AM/
The DSH stage electric chain hoist combines a high-strength aluminum housing with a precision stage-grade lifting mechanism, delivering quiet, reliable vertical lifting for professional rigging applications. Available in 0.5 t and 1 t capacities with variable speed control, it is built for concert trusses, theater productions, touring shows and exhibition setups that demand high safety and smooth load handling.
It shares core quality standards with industrial-grade hoists but is fully optimized for stage scenarios — featuring dual braking system, SIL3 emergency stopper, IP66 protection and EN818-7 certified load chain, plus a folding handle for convenient transportation. See the full specification below for detailed dimensions and performance data.
Independent mechanical and electromagnetic brakes ensure reliable and safe operation.
High-strength aluminum housing is lightweight, corrosion-resistant and rated up to IP66.
FEC DAT load chain meets EN818-7 standards, with forged alloy steel hook and CNC-machined load sprocket.
Folding handle and suspension design make transportation and maintenance more convenient.
Not every rigging project needs heavy industrial lifting capacity. For concert stages, theater productions, touring shows and exhibition trusses — where quiet operation, precise control, high safety and easy transport are top priorities — a purpose-built stage hoist outperforms standard industrial units. The DSH series is engineered for exactly that: smooth, silent, safety-rated vertical lifting for entertainment and event applications.
Which DSH model fits your job? If you need high-speed, lightweight lifting for small venues, light trusses and decorative installations, the DSH-S2-0.5 offers 1–26 m/min variable speed with a 0.5 ton capacity in a portable form. If you need higher load capacity for medium stages, heavy lighting rigs and speaker arrays, the DSH-S2-1 provides 1–16 m/min speed with a 1 ton rated load. Both are hook-suspended, fixed-point units ideal for permanent or temporary hanging positions where horizontal travel is not required.Compare: DSH-S2-0.5Compare: DSH-S1-0.5
| Model | DSH-S2-0.5 | DSH-S2-1 |
| Safety factor | 10:01 | 10:01 |
| Brake | 2 | 2 |
| Lifting speed | 1–26 m/min | 1–16 m/min |
| Functional safety certification | SIL3 | SIL3 |
| Noise | ≤65dB | ≤65dB |
| Chain | EN818-7 Φ6.3 × 19 mm | EN818-7 Φ7.1 × 21 mm |
| Limit switch | 2 | 2 |
| Overload protection | yes | yes |
| Load monitoring | yes | yes |
| Emergency Stopper | yes | yes |
| Hoist size | 536 × 262 × 217 mm | 536 × 262 × 217 mm |
| Flight case | 560 × 560 × 530 mm | 560 × 560 × 530 mm |
| Model | DSH-S2-0.5 | DSH-S2-1 |
| Capacity (t) | 0.5 | 1 |
| Test load (t) | 0.625 | 1.25 |
| Protection level | IP66 | IP66 |
| Classification FEM/SO | 1AM/M4 | 1AM/M4 |
| Lifting speed (m/min) | 1–26 | 1–16 |
| Motor (KW) | 2 | 2 |
| Load chain (mm) | Φ6.3×19 | Φ7.1×21 |
| Load chain falls | 1 | 1 |
| Net weight (KG) | 35 | 35 |
| Chain/M (kg) | 0.86 | 1.07 |
If the load only needs fixed-point vertical lifting on trusses, stage battens or lighting grids, the DSH hook-suspended stage hoist is the compact, reliable choice optimized for stationary rigging.
Choose from 0.5 t to 1 t based on your heaviest rigged load, plus an appropriate safety margin.
Confirm the hoist's mounting dimensions fit your truss hanging points and verify available headroom before ordering.
Select compatible supply voltage and control voltage to match your site’s electrical standard, with variable speed control for precise positioning.
SIL3-Certified Safety with Multi-Redundant Braking
Ultra-Low Noise Operation for Professional Performing Arts
Stepless Variable Speed Control for Precise Positioning
Lightweight Portable Design for Touring Applications
IP66 Ingress Protection with Long-Term Maintenance-Free Performance
Global Compliance with Wide Scenario Adaptability
What's the difference between the DSH-S2-0.5 and DSH-S2-1?
The DSH-S2-0.5 provides 0.5 t lifting capacity with 1–26 m/min variable speed; the DSH-S2-1 delivers 1 t capacity with 1–16 m/min lifting speed. Both share identical safety certifications, housing size and low-noise performance for professional stage rigging.
What capacities does the DSH stage hoist come in?
The DSH series covers 0.5 t to 1 t rated capacity, purpose-engineered for stage lighting, audio rigs, trusses and scenic elements.
How fast does the DSH electric stage hoist lift?
Standard variable lifting speed is 1–26 m/min for the 0.5 t model and 1–16 m/min for the 1 t model, powered by a 2.0 kW hoist motor with frequency control.
Can I get a trolley version for horizontal travel?
No — the DSH is a dedicated hook-suspended fixed-point hoist, built for stationary mounting on stage trusses, battens and lighting grids. It is not compatible with trolley systems.
What voltage and protection grade does the DSH support?
It carries an IP66 ingress protection rating, with adaptable supply voltage and 36V standard safety control voltage; 24V and 48V control options are available on request.
Tell us your capacity, lifting height, and working‑condition requirements — we'll confirm the correct model and send pricing.
