A geared electric trolley mounted electric chain hoist that travels along I-beam runways — built for monorail cranes and single-girder systems that need horizontal travel, not just fixed-point lifting.
The DLFP electric chain hoist with electric trolley pairs a compact chain hoist body with a geared electric trolley, giving the unit powered horizontal travel along an I-beam in addition to vertical lift. Available in capacities from 500 kg to 5000 kg with a 4 m lifting height, it's built for monorail cranes, single-girder crane runways, and assembly lines where a load needs to move along a fixed path, not just up and down.
It shares its lifting mechanism with the DLFP-N low headroom electric chain hoist, but adds travel — see the comparison below to confirm which fits your installation.
Geared electric trolley drives the hoist along the beam at 11/21 m/min, powered and controlled from the same pendant.
High-efficiency motor and gear reducer hold lifting speed under full load across the whole capacity range.
Sprocket replacement and brake inspection without dismantling the full unit.
110–480V input with a 36V standard safety control voltage (24V/48V optional) for global deployment.
Not every lifting job needs headroom optimization or powered travel. Where a load is lifted and lowered at one fixed station — a workbench, a single assembly point, a maintenance bay — a hook-suspended hoist does the job at lower cost and with less to maintain than a trolley-mounted or low-headroom unit. The DLF is built for exactly that: dependable, fixed-point lifting.
Which DLF/DLFP model fits your job? If your ceiling clearance is limited, the DLFP-N low headroom hoist reclaims lift height in a compact body. If your load needs to travel along a beam or runway, the DLFP with electric trolley adds powered horizontal movement. If you just need straightforward fixed-point lifting, the DLF hook type is the simpler, more economical choice.
Compare: DLFP-N Low HeadroomCompare: DLFP with Trolley
Capacity, lifting speed, power, voltage and travel speed by model
| Model | Capacity (kg) | Lift Height (m) | Lift Speed (m/min) | Power (kW) | RPM | Phases | Voltage (V) | Control V | Rating | Travel Speed (m/min) | Travel Power (kW) |
|---|---|---|---|---|---|---|---|---|---|---|---|
DLFP0.5-01 | 500 | 4 | 8 | 0.8 | 1440 | 3/2 | 110/480 | 24-48 | M5 | 11/21 | 0.75×2 |
| DLFP01-01 | 1000 | 4 | 4 | 1.1 | 1440 | 3/2 | 110/480 | 24-48 | M5 | 11/21 | 0.75×2 |
| DLFP01-02 | 1000 | 4 | 8 | 0.8 | 1440 | 3/2 | 110/480 | 24-48 | M5 | 11/21 | 0.75×2 |
| DLFP02-01 | 2000 | 4 | 7 | 1.1 | 1440 | 3/2 | 110/480 | 24-48 | M5 | 11/21 | 0.75×2 |
| DLFP02-02 | 2000 | 4 | 4 | 2.2 | 1440 | 3/2 | 110/480 | 24-48 | M5 | 11/21 | 0.75×2 |
| DLFP03-01 | 3000 | 4 | 7 | 3.0 | 1440 | 3/2 | 110/480 | 24-48 | M5 | 11/21 | 0.75×2 |
| DLFP03-02 | 3000 | 4 | 3.5 | 2.2 | 1440 | 3/2 | 110/480 | 24-48 | M5 | 11/21 | 0.75×2 |
| DLFP05-02 | 5000 | 4 | 3.5 | 2.0 | 1440 | 3/2 | 110/480 | 24-48 | M5 | 11/21 | 0.75×2 |
Note: please confirm the DLFP03-02 and DLFP05-02 power ratings (2.2kW at 3000kg vs 2.0kW at 5000kg) against your current engineering spec sheet before publishing — flagged for accuracy check.
All dimensions in mm
| Model | H | A | B | D | I | T | R |
|---|---|---|---|---|---|---|---|
| DLFP0.5-01 | 490 | 375 | 218 | 275 | 31 | 210 | Φ142 |
| DLFP01-01 | 510 | 400 | 243 | 290 | 31 | 210 | Φ142 |
| DLFP01-02 | 565 | 375 | 218 | 275 | 31 | 210 | Φ142 |
| DLFP02-01 | 640 | 490 | 258 | 425 | 36 | 230 | Φ142 |
| DLFP02-02 | 615 | 400 | 243 | 290 | 36 | 230 | Φ142 |
| DLFP03-01 | 695 | 490 | 258 | 425 | 43 | 230 | Φ142 |
| DLFP03-02 | 750 | 490 | 258 | 425 | 43 | 230 | Φ142 |
| DLFP05-02 | 830 | 490 | 258 | 425 | 54 | 230 | Φ142 |
If the load only needs to move vertically, the DLFP-N low headroom hoist is the simpler, more compact choice.
Choose from 500–5000 kg based on your heaviest rated load, plus safety margin.
Confirm the trolley's flange width range matches your I-beam before ordering.
Select from 110–480V supply and 24–48V control voltage to match your site's electrical standard.
Powered travel covers a full runway from one control pendant
Accessible electrical and brake component inspection
M5 duty rating suited to industrial-cycle lifting
Quick sprocket replacement without full unit disassembly
Multi-voltage support (110–480V) for global site deployment
Shares lifting mechanism with the DLFP-N for common spare parts
From what lifting scenarios can the CK hoist work?
It is used for vertical lifting and load holding in various working scenarios — fixed-point hoisting, workshop maintenance, site assembly and temporary overhead lifting paired with manual trolley.
What capacities does it come in?
The CK series covers 0.5t, 1t, 2t, 3t, 5t, 10t and 20t per unit, and can be extended up to 50t.
How does the safety mechanism work?
The hoist adopts dual-pawl brake system, which prevents load slipping during lifting, lowering and load suspension. All fasteners are fitted with anti-slip nuts to avoid loosening under heavy load and vibration.
What lifting heights are available?
Standard lifting height ranges from 2.5m to 3m, and customized lifting height is available upon request to meet different site requirements.
What standards does it comply with?
It is manufactured to EN 13157 standard with a 4:1 safety factor, suitable for industrial heavy-duty manual lifting operations.
Tell us your capacity, lifting height, and working‑condition requirements — we'll confirm the correct model and send pricing.
Request a Quote
