DIAMOND SQUARE STEEL CHAIN
Diamond Square Steel Chain-Ring With Wear Blocks
High strength & heavy-duty load capacity
Excellent wear resistance & long service life
Stable transmission & smooth running
High tensile strength, not easy to break
Good fatigue resistance
Corrosion resistance & durable in harsh environment
Precise pitch, low noise
| ITEM NO | WIRE DIAMETER | TIRE SIZE | WEIGHT/Pair(kg) |
| WB15-9.5 | 9.5 | 14.00-24;15.5-25;17.5L24;16.9-24 | 146 |
| WB24-9.5 | 9.5 | 17.5-25;16.00-20 | 154 |
| WB27-9.5 | 9.5 | 16.00-24;16.00-25;19L-24 | 161 |
| WB33-9.5 | 9.5 | 20.5-25;18.00-25;18.4-30;21L-24 | 175 |
| WB45-9.5 | 9.5 | 23.5-25;21.00-25;20.8-34;25/65-25 | 207 |
| WB57-9.5 | 9.5 | 26.5-25;26.5-29;24.00-25;24.5-32 | 241 |
| WB15-11 | 11 | 14.00-24;15.5-25;17.5L24;16.9-24 | 189 |
| WB24-11 | 11 | 17.5-25;16.00-20 | 207 |
| WB27-11 | 11 | 16.00-24;16.00-25;19L-24 | 211 |
| WB33-11 | 11 | 20.5-25;18.00-25;18.4-30;21L-24 | 228 |
| WB45-11 | 11 | 23.5-25;21.00-25;20.8-34;25/65-25 | 268 |
| WB57-11 | 11 | 26.5-25;26.5-29;24.00-25;24.5-32 | 304 |
| WB72-11 | 11 | 29.5-25;30.5-32 | 342 |
| WB15-13 | 13 | 14.00-24;15.5-25;17.5L24;16.9-24 | 285 |
| WB24-13 | 13 | 17.5-25;16.00-20 | 312 |
| WB27-13 | 13 | 16.00-24;16.00-25;19L-24 | 317 |
| WB33-13 | 13 | 20.5-25;18.00-25;18.4-30;21L-24 | 324 |
| WB36-13 | 13 | 21L-24 | 494 |
| WB45-13 | 13 | 23.5-25;21.00-25;20.8-34;25/65-25 | 375 |
| WB57-13 | 13 | 26.5-25;26.5-29;24.00-25;24.5-32 | 429 |
| WB72-13 | 13 | 29.5-25;30.5-32 | 457 |
